MIL-DTL-44117B
TABLE III. Material and component verification
Materials and
Requirement paragraph
Verification
components
Edging
3.5.2
ASTM D 2000
Cloth, Ballistic, Aramid
3.5.1.1
MIL-DTL-44050
Adhesive
3.5.2.1, 3.7.4, 3.7.5
4.4.5
Coating
3.5.3
MIL-DTL-64159
Bar code label/tag
3.5.6.4
MIL-DTL-32075
4.4.1 In process inpection. Visual and dimensional examinations of the helmet and its
components or subassemblies shall be made at any point or during any phase of the manufacturing
process to determine whether construction details which cannot be examined in the finished
product are in accordance with requirements specified in Sections 3. Materials and components
which can be classified as a defect in accordance with Table VI, Table VII, and or Table VIII shall
be removed from production.
4.4.1.1 Visual and dimensional examination of components. Components shall be visually and
dimensionally examined in accordance with Table IV. The sample unit and sample size shall be as
designated below and in Table IV unless otherwise specified in the solicitation or contract. Any
measurement not conforming to the specified dimension shall be cause for rejection of the
applicable component lot.
Lot size
Sample size
800 or less
2
801 up to and including 22,000
3
22,001 and more
5
TABLE IV. Inspection of components for dimensions
Component
Dimensional Number of
Results reported Sample unit
Requirement Determinations Numerically
(Drawing #) (Per unit)
To nearest
Buckle
8-2-605
1/
2/
1 buckle
Edge beading 8-2-644
1/
2/
1 yard or 1 piece of
8-2-607
molded construction
Post
8-2-647
1/
2/
1 post
8-2-610
Attachment
8-2-601
1/
2/
1 Attachment
strip/Fastener
strip/fastener tape
tape
Attachment
8-2-604
1/
2/
1 attachment tab
tabs
1/ One determination shall be made for each specified dimension.
2/ Results shall be reported to the nearest .001 inch or 1/64th of an inch unless otherwise indicated
in the drawings.
15
